Description
FIBC Bags, also known as Flexible Intermediate Bulk Containers, Bulk Bags, or Jumbo Bags, are heavy-duty PP woven bags designed for the storage, handling, and transportation of dry bulk materials. Made from high-strength polypropylene woven fabric, FIBC Bags provide a reliable and cost-effective packaging solution for a wide range of industrial and commercial applications.
Key Features
• High-strength PP woven fabric for reliable load-bearing performance.
• Large capacity for efficient packaging and transportation of bulk materials.
• Flexible construction for convenient storage and handling when empty.
• Multiple lifting loop, filling, and discharge options to meet different handling requirements.
• Optional inner liners, coating, and printing for specific product and packaging needs.
Construction Options
FIBC Bags are available in different constructions, including U-panel, four-panel, circular, and baffle designs. The suitable construction can be selected according to the required capacity, strength, shape retention, and transportation conditions.
Top and Bottom Options
Different top and bottom designs are available to match different filling and discharge processes. Common options include open top, duffle top, filling spout, flat bottom, and discharge spout.
Applications
FIBC Bags are widely used for packaging and transporting chemicals, fertilizers, minerals, grains, animal feed, construction materials, and other dry bulk products. They are suitable for warehouse storage, container transportation, and efficient bulk-material handling.
Customization
FIBC Bags can be customized according to customer requirements, including bag size, capacity, fabric construction, lifting loops, filling and discharge designs, inner liner, coating, UV stabilization, printing, and other specifications.
We provide customized FIBC Bag solutions for different bulk packaging and transportation requirements. Contact us with your required capacity, dimensions, material, bag construction, and application to discuss a suitable FIBC Bag solution.
Technical Specification
| SWL Range | 500 kg to 2000 kg. |
| SF Option | 5:1 / 6:1 |
| Lifting Option | One loop, Two loop, Four loop, Tunnel loop. Loops made from PP loop (standard loops), PP Multifilament loops (for soft loops), PP fibrillated loops (for semi soft loops) available in various designs & colours. |
| Filling Option | Filling spout, Skirt (duffle top), Flap |
| Discharge Option | Discharge spout, Iris (Pyjama/Bonout), Star closer (Petle closer) & Conical |
| Liner | With or without liner. Liners comes in Loose, Glued, Tabbed, Stitched Liners, Suspended liners and form fit/ shape liners. |
| Printing Options | Printed (up to 4 colour) and unprinted. |
| Sewing Options | Heracle & safety, double chain with or without dustproof. |
| Sewing Thread/Webbing | In various colours including blue, black, green and red. All Colours defined by Pantone system |
| Document Pockets | Ziplock – In various sizes and materials including transparent PE and transparent PP. Also available in self-closing type. |
| Fabric | Flat woven or tubular woven fabric with Coated or uncoated. |
| Extrusion | We produce 600 kgs per hour of PP tapes of various GSM and Strengths. We have the Beta gauge machines which continuously check the size and the denier of the tape. |
| Looms | High speed circular looms to produce quality fabric of any width and GSM. |
| Belt Weaving | Needle loom Machine for Loop and Dust proof making. |
| Lamination | Extrusion Coating Plant for fabrics lamination (width 2.2 meters). |
| Testing Lab | We have latest equipment of Tensile Testing, Elongation Testing, UV Testing, Load Test, Dart Impact Test, COF Testing & RIG Test to ensure Tape, Belt, Fabrics and bag quality. |
Customized Size FIBC/Jumbo Bag Specifications
| Color | White or Customize |
| Material | 100% PP |
| Shapes | U-Panel |
| Top Option (Filling) | Full open/ with spout/with skirt cover |
| Loop Option (Lifting) | Cross Corner Loop/Single Loop/Two Loops |
| Bottom Option (Discharge) | Discharge spout or flat bottom |
| Sewing | Plain/chain/chain lock with optional soft-proof |
| Characteristics | Breathable,airy,anti-static,conductive,UV,stabilization,reinforcement,dust |
| Packaging | Packing in bales or pallets |
| Dimension | 90*90*110cm/100*100*120cm or as customers’ requirements |
| Certification | SGS,ISO9001, CE,food-grade production qualification |
| Safety Factor | 5:1 |
| Fabric Weight | 120g / m2-240g/ m2 |
| Loading Weight | 500KG-3000KG |
| Liner | Liner( HDPE,LDPE) or as customers’ requirements |
| Fabric Weight | 120g / m2-240g/ m2 |
